Subaru Legacy: Trailer towing
Your vehicle is designed and intended to be used primarily as a passenger-carrying vehicle. Towing a trailer puts additional loads on your vehicle’s engine, drivetrain, brakes, tires and suspension and has an adverse effect on fuel economy.
If you do decide to tow a trailer, your safety and satisfaction depend upon proper use of correct equipment and cautious operation of your vehicle. Seek the advice of your SUBARU dealer to assist you in purchasing a hitch and other necessary towing equipment appropriate for your vehicle. In addition, be sure to follow the instructions on correct installation and use provided by the trailer and other towing equipment manufacturers.
SUBARU assumes no responsibility for injuries or vehicle damage that result from trailer towing equipment, or from any errors or omissions in the instructions accompanying such equipment or for your failure to follow the proper instructions.
When you do not tow a trailer
● Remove the ball mount from the hitch receiver tube and insert the receiver
cover onto the hitch receiver tube.
● Place the dust cap over the four-pin connector of the hitch wire harne ...
Warranties and maintenance
vehicle damage or malfunction caused by trailer towing. If you use your vehicle
to tow a trailer, more frequent maintenance will be required due to the additional
load. (Refer to “Maintenance sc ...
