Hyundai Sonata: Engine compartment - Your vehicle at a glance - Hyundai Sonata Owners ManualHyundai Sonata: Engine compartment

  1. Engine coolant reservoir
  2. Engine oil filler cap
  3. Brake/clutch fluid reservoir
  4. Air cleaner
  5. Fuse box
  6. Positive battery terminal
  7. Negative battery terminal
  8. Windshield washer fluid reservoir
  9. Radiator cap
  10. Engine oil dipstick
